1 Hour to Figma
Design your first real interface from blank canvas to clickable prototype in 60 minutes
By the end of this hour, you'll have a complete mobile app interface with interactive navigation and a working prototype ready for user testing.
🎯 What You'll Build
A fully interactive food delivery app with 4 screens: splash screen, login page, restaurant list, and menu details. The prototype will include tap animations, screen transitions, and realistic interactions you can test on your phone.
Your final design will feature a clean interface with a logo, form inputs, image cards, buttons, and smooth transitions between screens that feel like a real app.
⏱️ Time Breakdown
📋 Prerequisites
- Figma account (free at figma.com)
- Basic computer navigation skills
- Understanding of mobile apps (you use them daily)
- Chrome or Safari browser
Step 1: Create Your Canvas (0–12 min)
Open Figma and click "New Design File". Press F to open the Frame tool, then select "iPhone 14" from the right panel.
Create your splash screen first. Press T for text tool and add your app name "FoodieGo" in the center. Make it size 32, weight Bold.
Add a simple logo using the ellipse tool (O). Draw a circle, fill it with #FF6B35 (orange), then add a smaller white circle inside for a simple food icon.
Position everything in the center using the alignment tools in the right panel.
Checkpoint
Can you see a centered app name and orange logo on your iPhone frame?
Rename this frame to "Splash" in the layers panel (left side). This keeps your work organized.
Create three more iPhone frames by duplicating (Cmd+D on Mac, Ctrl+D on Windows). Arrange them horizontally and rename them: "Login", "Restaurant List", "Menu Details".
Step 2: Design Login Interface (12–28 min)
Select your "Login" frame. Add a welcome message at the top: "Welcome Back" in size 28, Bold weight.
Create input fields using rectangles (R). Draw a rectangle 327×56 pixels, fill it white, add border stroke 1px #E5E5E5, corner radius 8px.
Add placeholder text inside: "Email address" in size 16, color #999999. Position it 16px from the left edge.
Duplicate this input field (Cmd+D) and change the placeholder to "Password". Stack them 16px apart vertically.
Create a login button: rectangle 327×56px, fill #FF6B35, corner radius 8px. Add white text "Sign In" centered inside.
Add a "Forgot Password?" link below using text tool, size 14, color #FF6B35.
Checkpoint
Does your login screen have email/password inputs and an orange Sign In button?
Step 3: Build Restaurant Grid (28–42 min)
In your "Restaurant List" frame, add a header "Nearby Restaurants" at the top, size 24, Bold.
Create a restaurant card using rectangles. Make the main card 327×120px with white fill, corner radius 12px, and drop shadow (Effects → Drop Shadow, Y:2, Blur:8, Color:#00000015).
Add a placeholder image area: rectangle 80×80px, fill #F0F0F0, corner radius 8px. Position it 16px from left edge.
Add restaurant details with text:
- Restaurant name: "Pizza Palace", size 18, Bold
- Cuisine type: "Italian • Fast Food", size 14, color
#666666 - Rating: "4.5 ⭐ (120 reviews)", size 12, color
#666666
Stack these text elements vertically, 16px from the image.
Duplicate this card 3 times (Cmd+D). Change the restaurant names to "Burger Barn", "Sushi Spot", and "Taco Time". Adjust cuisine types accordingly.
Space cards 12px apart vertically.
Step 4: Create Menu Screen (42–52 min)
In "Menu Details" frame, add restaurant header with back arrow. Use text left-arrow for the arrow, size 20, then "Pizza Palace" next to it, size 20, Bold.
Create menu item cards similar to restaurant cards but 327×100px. Add:
- Food image placeholder: 70×70px rectangle,
#F0F0F0fill - Item name: "Margherita Pizza", size 16, Bold
- Description: "Fresh mozzarella, basil, tomato sauce", size 14, color
#666666 - Price: "$12.99", size 16, Bold, color
#FF6B35
Create 4 menu items: "Margherita Pizza", "Pepperoni Special", "Caesar Salad", "Garlic Bread".
Add a floating "Add to Cart" button at bottom: 343×56px, fill #FF6B35, corner radius 28px. Center white text "Add to Cart • $25.98".
Checkpoint
Can you see menu items with prices and an orange "Add to Cart" button at the bottom?
Step 5: Ship It (52–60 min)
Switch to Prototype mode (top right, next to "Design").
Connect your screens by clicking the blue + icon on each frame:
- Splash → Login (After Delay, 2000ms)
- Login button → Restaurant List (On Tap, Instant)
- Restaurant card → Menu Details (On Tap, Push Left)
- Back arrow → Restaurant List (On Tap, Push Right)
Set your starting point by clicking the play icon on the Splash frame.
Test your prototype by clicking the play button (top right). You should be able to tap through all screens smoothly.
Click "Share" (top right), then "Copy link" to get a shareable prototype URL you can open on your phone.
🎉 Congratulations! You've built a complete app interface with working navigation. Your prototype demonstrates real UX skills that impress clients and employers.
🎁 Bonus
- Add micro-interactions: heart icons that animate when tapped on restaurant cards
- Create component library: turn your buttons and cards into reusable components
- Design dark mode versions using Figma's color variables feature
